Inside Macintosh: Mac OS Runtime Architectures /

Chapter 1 - CFM-Based Runtime Architecture / Preparing a Closure

Checking for Compatible Import Libraries

Checking compatibility between a client fragment and an import library essentially means checking for an intersection between the version range required by the client fragment and the range supported by the import library.

When building a fragment that requires an import library, you must supply information in a definition stub library that defines the library's API. A stub library contains symbol definitions but does not contain actual code. The linker uses definition stub libraries to associate imported symbols with particular import libraries. Figure 1-8 shows an application linking to a definition stub library to produce the completed application. A reference such as cowLib:setWindow means that the symbol setWindow can be found in the import library cowLib.

Figure 1-8 Linking to a definition stub library

An import library that provides implementation code is dynamically linked to the client fragment by the Code Fragment Manager during the preparation process. This library (sometimes called the implementation library) must be fully functional.

Note

Since an implementation library contains symbol definitions, the implementation library can act as a definition stub library at link time.

Figure 1-9 shows an implementation library bound to the application at runtime.

Figure 1-9 Using the implementation version of a library at runtime

The definition stub library may not be the same version as the implementation library (one may be an earlier version, for example), so the Code Fragment Manager must check to make sure that they are compatible. Generally the libraries are compatible if the library used at runtime can satisfy the programming interface defined for it during the build process.

When building an import library, you determine compatibility by defining version numbers. You should set three version numbers (usually by specifying linker options) for use in version checking:

• the current version number of the library you are creating
• the old implementation version number, which is the oldest version of this library available at runtime that supports the client's needs
• the old definition version number, which is the oldest version of the library defined for the client fragment that is supported by the library you are creating

When building a client fragment, the linker stores the current version and old implementation version numbers of the import library in the client. Later, when the Code Fragment Manager prepares the client fragment, it uses this information to check for a compatible import library.

Table 1-1 shows two different versions of an import library cowLib and their version numbers.

Table 1-1 Two import libraries and their version numbers

Name	Current version number	Old definition version number	Old implementation version number
cowLib 13	13	9	10
cowLib 16	16	12	14

IMPORTANT

The current version number must always be greater than or equal to both the old definition version number and the old implementation version number.

If you build an application mooApp with cowLib 13 and attempt to run with cowLib 16, the compatibility ranges are as follows:

• cowLib 13 is not compatible with implementations of cowLib earlier than version 10 (its old implementation number is set to 10).
• cowLib 16 (present in the Extensions folder, for example) is not compatible with definitions of cowLib earlier than version 12 (its old definition version number is set to 12).

Figure 1-10 shows the compatibility ranges graphically.

Figure 1-10 Library versions compatible with each other

The presence of an overlap between the two areas of compatibility indicates that the two import libraries are compatible in this case.

However, reversing the roles of the two libraries (building with cowLib 16, executing with cowLib 13) results in a different set of compatibility ranges as follows:

• cowLib 16 is not compatible with implementations of cowLib earlier than version 14 (the old implementation version number is 14).
• cowLib 13 is not compatible with definitions of cowLib earlier than version 9 (the old definition version number is 9).

In this case the two libraries are incompatible, as shown in Figure 1-11.

Figure 1-11 Library versions incompatible with each other

The library cowLib 16 may (for example) include additional routines that are not supported by versions older than 14.

The Code Fragment Manager uses the algorithm shown in Listing 1-1 for checking import library compatibility. It uses this algorithm to check the compatibility of the fragment being prepared with all the import libraries from which it imports code and data.

Listing 1-1 Pseudocode for the CFM version-checking algorithm

if (Definition.Current == Implementation.Current)
   return(kLibAndAppAreCompatible);
else if (Definition.Current > Implementation.Current)
   /*definition version is newer than implementation version*/
   if (Definition.OldestImp <= Implementation.Current)
      return(kImplAndDefAreCompatible);
   else
      return(kImplIsTooOld);
else
   /*definition version is older than implementation version*/
   if (Implementation.OldestDef <= Definition.Current)
      return(kImplAndDefAreCompatible);
   else
      return(kDefIsTooOld);

The fact that only one instance of an import library can appear in a given process may cause versioning conflicts. For example say an application mooApp uses the import library mooLib. If mooApp loads a plug-in mooPlug that also requires mooLib, then the Code Fragment Manager uses the available connection for mooLib. If this version is not compatible with the version required by the plug-in, then the preparation of the plug-in fails. (This failure occurs even if you designated mooLib to be weak.)
