How to get a 2D floor plan with dimensions from RoomPlan

```swift
  private func getLargestSurface() {
    largestSurface = surfaces.first
    for surface in surfaces {
      if surface.dimensions.x > largestSurface?.dimensions.x ?? 0 {
        largestSurface = surface
      }
    }
  }
```

here do the extra rotations for each wall.

I also added a basic dimension calculator to demonstrate how this might look converting from the RoomPlan dimensions. This is not super useful in its current state but I was just playing around and figured I would share my findings.
```
//
//  FloorPlanSurface.swift
//  RoomPlan 2D
//
//  Created by Dennis van Oosten on 12/03/2023.
//

import SpriteKit
import RoomPlan

class FloorPlanSurface: SKNode {

  private let capturedSurface: CapturedRoom.Surface

  // MARK: - Computed properties

  private var halfLength: CGFloat {
    return CGFloat(capturedSurface.dimensions.x) * scalingFactor / 2
  }

  private var pointA: CGPoint {
    return CGPoint(x: -halfLength, y: 0)
  }

  private var pointB: CGPoint {
    return CGPoint(x: halfLength, y: 0)
  }

  private var pointADim: CGPoint {
    return CGPoint(x: -halfLength, y: -dimensionLineDistFromSurface)
  }

  private var pointBDim: CGPoint {
    return CGPoint(x: halfLength, y: -dimensionLineDistFromSurface)
  }

  private var pointC: CGPoint {
    return pointB.rotateAround(point: pointA, by: 0.25 * .pi)
  }

  // MARK: - Init

  init(capturedSurface: CapturedRoom.Surface) {
    self.capturedSurface = capturedSurface

    super.init()

    // Set the surface's position using the transform matrix
    let surfacePositionX = -CGFloat(capturedSurface.transform.position.x) * scalingFactor
    let surfacePositionY = CGFloat(capturedSurface.transform.position.z) * scalingFactor
    self.position = CGPoint(x: surfacePositionX, y: surfacePositionY)
      .rotateAround(
        point: CGPointZero,
        by: -CGFloat(largestSurface?.transform.eulerAngles.y ?? 0)
      ) //this rotation will rotate each point around an arbitrary point to get the roration of midpoints in the correct location

    // Set the surface's zRotation using the transform matrix
    // the additional largest surface rotation here will get the new angle offset for each wall. i.e. if this is the largest wall the rotation will be 0 - largest wall rotation + largest wall rotation. this essentially brings it back to a horizontal angle.
    self.zRotation = -CGFloat(capturedSurface.transform.eulerAngles.z - capturedSurface.transform.eulerAngles.y + (largestSurface?.transform.eulerAngles.y ?? 0))

    // Draw the right surface
    switch capturedSurface.category {
    case .door:
      drawDoor()
    case .opening:
      drawOpening()
    case .wall:
      drawWall()
    case .window:
      drawWindow()
    @unknown default:
      drawWall()
    }
  }

  required init?(coder aDecoder: NSCoder) {
    fatalError("init(coder:) has not been implemented")
  }

  // MARK: - Draw

  private func drawDoor() {
    let hideWallPath = createPath(from: pointA, to: pointB)
    let doorPath = createPath(from: pointA, to: pointC)

    // Hide the wall underneath the door
    let hideWallShape = createShapeNode(from: hideWallPath)
    hideWallShape.strokeColor = floorPlanBackgroundColor
    hideWallShape.lineWidth = hideSurfaceWith
    hideWallShape.zPosition = hideSurfaceZPosition

    // The door itself
    let doorShape = createShapeNode(from: doorPath)
    doorShape.lineCap = .round
    doorShape.zPosition = doorZPosition

    // The door's arc
    let doorArcPath = CGMutablePath()
    doorArcPath.addArc(
      center: pointA,
      radius: halfLength * 2,
      startAngle: 0.25 * .pi,
      endAngle: 0,
      clockwise: true
    )

    // Create a dashed path
    let dashPattern: [CGFloat] = [24.0, 8.0]
    let dashedArcPath = doorArcPath.copy(dashingWithPhase: 1, lengths: dashPattern)

    let doorArcShape = createShapeNode(from: dashedArcPath)
    doorArcShape.lineWidth = doorArcWidth
    doorArcShape.zPosition = doorArcZPosition

    addChild(hideWallShape)
    addChild(doorShape)
    addChild(doorArcShape)
    drawBackWallCaps()
  }

  private func drawOpening() {
    let openingPath = createPath(from: pointA, to: pointB)

    // Hide the wall underneath the opening
    let hideWallShape = createShapeNode(from: openingPath)
    hideWallShape.strokeColor = floorPlanBackgroundColor
    hideWallShape.lineWidth = hideSurfaceWith
    hideWallShape.zPosition = hideSurfaceZPosition

    addChild(hideWallShape)
    drawBackWallCaps()
  }

  private func drawWall() {
    let wallPath = createPath(from: pointA, to: pointB)
    let wallShape = createShapeNode(from: wallPath)
    wallShape.lineCap = .round

    let dimensionsPath = createDimPath(from: pointADim, to: pointBDim)
    let dimensionsShape = createDimNode(from: dimensionsPath)
    dimensionsShape.lineCap = .round

    let dimensionsLabel = createDimLabel()

    addChild(wallShape)
    addChild(dimensionsShape)
    addChild(dimensionsLabel)
  }

  private func drawWindow() {
    let windowPath = createPath(from: pointA, to: pointB)

    // Hide the wall underneath the window
    let hideWallShape = createShapeNode(from: windowPath)
    hideWallShape.strokeColor = floorPlanBackgroundColor
    hideWallShape.lineWidth = hideSurfaceWith
    hideWallShape.zPosition = hideSurfaceZPosition

    // The window itself
    let windowShape = createShapeNode(from: windowPath)
    windowShape.lineWidth = windowWidth
    windowShape.zPosition = windowZPosition

    addChild(hideWallShape)
    addChild(windowShape)

    drawBackWallCaps()
  }

  // MARK: - Helper functions

  private func createPath(from pointA: CGPoint, to pointB: CGPoint) -> CGMutablePath {
    let path = CGMutablePath()
    path.move(to: pointA)
    path.addLine(to: pointB)

    return path
  }

  private func createDimPath(from pointA: CGPoint, to pointB: CGPoint) -> CGMutablePath {
    let path = CGMutablePath()
    // edges of dimension line
    path.move(to: CGPoint(x: pointA.x, y: pointA.y-surfacedWidth))
    path.addLine(to: CGPoint(x: pointA.x, y: pointA.y+surfacedWidth))
    path.move(to: CGPoint(x: pointB.x, y: pointB.y-surfacedWidth))
    path.addLine(to: CGPoint(x: pointB.x, y: pointB.y+surfacedWidth))

    // main line with gap for label
    path.move(to: pointA)
    path.addLine(to: CGPoint(x: -dimensionLabelWidth/2, y: -dimensionLineDistFromSurface))
    path.move(to: pointB)
    path.addLine(to: CGPoint(x: dimensionLabelWidth/2, y: -dimensionLineDistFromSurface))

    return path
  }


  private func createDimLabel() -> SKLabelNode {
    let dimTotalInches = self.capturedSurface.dimensions.x*metersToInchesFactor
    let feet = Int(dimTotalInches/12)
    let inches = Int(round(dimTotalInches)) % 12

    let label = SKLabelNode(text: "\(feet)' \(inches)''")
    label.fontColor = floorPlanSurfaceColor
    label.position.y = -dimensionLineDistFromSurface - labelFontSize/2
    label.fontSize = labelFontSize
    label.fontName = labelFont

    return label
  }

  private func createShapeNode(from path: CGPath) -> SKShapeNode {
    let shapeNode = SKShapeNode(path: path)
    shapeNode.strokeColor = floorPlanSurfaceColor
    shapeNode.lineWidth = surfacedWidth

    return shapeNode
  }

  private func createDimNode(from path: CGPath) -> SKShapeNode {
    let shapeNode = SKShapeNode(path: path)
    shapeNode.strokeColor = floorPlanSurfaceColor
    shapeNode.lineWidth = dimensionWidth

    return shapeNode
  }

  private func drawBackWallCaps() {
    let lineWidth: CGFloat = 1
    let capA = SKShapeNode(circleOfRadius: surfacedWidth/2-lineWidth/2)
    let capB = SKShapeNode(circleOfRadius: surfacedWidth/2-lineWidth/2)
    capA.lineWidth = lineWidth
    capB.lineWidth = lineWidth
    capA.position = pointA
    capB.position = pointB
    capA.fillColor = floorPlanSurfaceColor
    capB.fillColor = floorPlanSurfaceColor
    capA.strokeColor = floorPlanSurfaceColor
    capB.strokeColor = floorPlanSurfaceColor
    capA.zPosition = hideSurfaceWallCapZPosition
    capB.zPosition = hideSurfaceWallCapZPosition

    addChild(capA)
    addChild(capB)
  }
}
```
