visionOS上のイマーシブなWebサイト環境の詳細

1:51 - Basic model element

<model src="teapot.usdz">
</model>

2:06 - Model element with environment map

<model src="teapot.usdz"
	environmentmap="kitchen.hdr">
</model>

4:40 - Adding the environment model on the page for inline preview

<div class="seat-preview">
	<model id="theater"
		   src="theater-model.usdz"
		   environmentmap="theater-lighting.hdr">
	</model>
</div>

5:14 - Reset the model entity transform

const theater = document.getElementById("theater");

async function updateModelTransform() {
	// Make sure the model is loaded
	await theater.ready;
	// Create a transform matrix
	const identity = new DOMMatrix();
	// Apply the transform matrix to the model
	theater.entityTransform = identity;
}

updateModelTransform();

5:42 - Translate the model down

const theater = document.getElementById("theater");

async function updateModelTransform() {
	// Make sure the model is loaded
	await theater.ready;
	// Create a transform matrix
	const transform = new DOMMatrix();
	// Translate model down, for eye level preview
	transform.translateSelf(
		0, 			// x
		-1.0, 	// y
		0 			// z
	);
	// Apply the transform matrix to the model
	theater.entityTransform = transform;
}

updateModelTransform();

6:40 - Build the seat transform

function buildTransform(seat) {
	const transform = new DOMMatrix();
	const { x, y, z, ry } = seat;
	// Rotate and translate the model to match
  // the seat's origin and orientation
	transform.rotateSelf(0, -ry, 0);
	transform.translateSelf(-x, -y, -z);
	// Translate the model down, for eye level preview
	transform.translateSelf(0, -1.0, 0);
	return transform;
}

7:16 - Detect feature availability

if (document.immersiveEnabled) {
	immersiveButton.hidden = false;
}

7:34 - Request the immersive transition on the model

immersiveButton.addEventListener("click", async () => {
	await model.requestImmersive();
});

8:24 - Build immersive transform

function buildTransform(seat, immersive) {
	const transform = new DOMMatrix();
	// [...] Seat transform logic
	if (immersive) {
		// Rotate to the left
		transform.rotateSelf(
			0,		// x
			45,		// y
			0			// z
		);
	} else {
		// [...] Eye level translation
	}
	return transform;
}

9:01 - Update the entity transform and the layout on immersive state updates

theater.addEventListener("immersivechange", () => {
	const isImmersive = !!document.immersiveElement;
	const transform = buildTransform(isImmersive, currentSeat);
	theater.entityTransform = transform;
  document.body.classList.toggle("immersive", isImmersive);
});

10:53 - Hide the inline preview

<model id="escapeRoom"
	   src="escape-room.usdz"
	   environmentmap="room-lighting.hdr"
	   style="display: none">
</model>

11:25 - Request an immersive transition on the escape room model

const enterButton = document.getElementById("enterButton");
const escapeRoom = document.getElementById("escapeRoom");

enterButton.addEventListener("click", () => {
    await escapeRoom.requestImmersive();
});

11:52 - Handle the request result and show a loading animation

enterButton.addEventListener("click", async () => {
	showLoadingAnimation();
	try {
		await escapeRoom.requestImmersive();
	} catch (error) {
		console.log(error);
	} finally {
		hideLoadingAnimation();
	}
});

13:16 - Dock the video in the environment with the fullscreen API

const trailerVideo = document.getElementById("trailerVideo");
const demoButton = document.getElementById("demoButton");

demoButton.addEventListener("click", async () => {
	await trailerVideo.requestFullscreen();
});

14:01 - Play the model animation

const trailerVideo = document.getElementById("trailerVideo");
const escapeRoom = document.getElementById("escapeRoom");

trailerVideo.addEventListener("ended", async () => {
	await document.exitFullscreen();
	escapeRoom.play();
});

16:38 - Compress your USDZ with usdcrush

usdcrush model.usdz -o optimized.usdz
